LG-2 Automatic paper Unloader
Key words:
Classification:
Keyword： LG-2 Automatic paper Unloader
E-mail:
Main Technical Parameters
| Model | unit | LG-2 |
| Maximum size | cm | 90x126 |
| Minimum size | cm | 40x40 |
| Maximum height per ream | cm | 16 |
| Minimum height per ream | cm | 4.5 |
| Maximum stack height (with base plate) | cm | 140 |
| Maximum loading capacity | Kg | 200 |
| weight | Kg | 1500 |
| Machine width | cm | 320 |
| Machine depth | cm | 180 |
| Machine height | cm | 220 |
| voltage | V | 380 |
| power | V | 2 |
| compressor | V/min Bar | 6-8 |
Product Description
The fully automatic paper unloader can automatically stack the paper neatly. The operator only needs to put the cut paper on the paper unloader on the workbench, the paper unloader automatically puts the paper neatly on the tray, and the full-automatic paper unloader can improve the production and cutting output .The function of stacking paper neatly brings great convenience to the subsequent workflow.
Program control
1. The function of automatic paper feeding, unloading and stacking can quickly unload the paper from the workbench and stack it neatly at the designated position,Greatly reduce the labor intensity of workers.
2. The infrared position detection device can accurately detect the position of the paper and ensure that the paper is stacked neatly.
3. Anti-impact flexible bumper can effectively prevent accidental impact during machine movement.
4. The paper clamping pneumatic control can safely clamp the paper and protect the edges and corners of the paper from external forces.
5. High-performance motor, imported from Taiwan.
6. It is equipped with 10.4 inch touch screen to make the operation simple and easy.
7. Comply with ergonomics to avoid operation injury.
8. Overweight safe parking protection is optimized and designed.
9. The working platform is equipped with air blowing structure to facilitate paper pushing and unloading.
10. The chrome-plated working platform saves users' maintenance time.
